  Pa0nhc PCB catalog. Carefully RF-designed PCBs in perfect quality. Update 20181012.
Please help me developing new projects by ordering these PCBs.

HOW to order PCBs.
>> DO print and keep a (printed) copy of the actual version of the accompanying article. <<

            My PCB prices are :
- including free worldwide shipment,
- in bubble envelop,
- cheapest postage,
- no track and trace,
- nor CN22/23 form.

If you want Track and trace, it costs 15 Euro extra on top of the total cost.

Delivery time after postage depends on the distance and post companies.
It varies between one day to a few weeks.

After a PCBfactory reorder by me, i sometimes have to pay extra DHL costs.
These costs can be up to 50% on top of the PCB+shipment costs, and will then be included into new prizes !

20180912 : Due to recently lowered max. weight / stamp specifications by our post company, some PCB prizes had to be adapted.

            Parts.
In the building descriptions, i give parts lists including part ordering numbers for "www.conrad.nl".
BUT Conrad only sells to western EU, and does not sell worldwide.
        If Conrad does not sell to your country :
- read the parts technical details on www.conrad.nl , using the given Conrad ordering number.
- use these details to order an equal component elsewhere.

            KITS.
No building kits are available.
I am a 79 year old pensioner, with very limited finances. This PCB service is just a part of my radio amateur hobby.
I cannot keep stock for all components. Sorry.

            Parts available together with PCBs :
I sometimes offer a few cheap and small parts together with PCBs. A few specialized parts are not available even at Conrad, and must be ordered at eBay or elsewhere. If you order these parts together with the PCB, you do not have to order them elsewhere with costly extra postage charges for you.

            Assembled PCBs.
I sometimes offer completed build PCBs, without housing nor connection materials (because weight and size rises the postage costs to much !).

As soon as is payed for the order, i will order parts not in stock, and build it.
Postage time can be up to two weeks after secure payment via Paypal.

            Working for others for free is not my hobby.
I therefore include in the total price money for component material costs, component postage costs, component ordering time, construction time and testing time. As well as for packaging, insurance , track and trace, and postage of the finished product. This all add-up.

            You want to keep it cheap? Then order parts, construct and test it yourselves.

3.7MHz 0dBm generator
for calibrating S-meters.
20180804

Complete PCB set including housing parts.

Building description

Seven PCBs : 17.50 Euro.

50 Ohm 63 dB fixed attenuator
for calibrating S-meters. 20180731

Complete 7 PCB set including housing
(without resistors).

Building description

50 Ohm 75 dB / 1dB-step attenuator
for calibrating S-meters. 20180810

Building description

Xfilter active RF noise canceller.
PCB : 20.-- Euro.

Youtube demo

Building description

Automatic Loop Tuner.

PCB set price -----  Euro. Available June / July .
A4 manual -----  Euro

Building description  under reconstruction.
Updated PCB designs.
Reducing wiring.
Updated  component placement.
Updated component indications.

Handy manual loop tuner.

PCB price : Euro 15.--

Building description.

MAGNETIC (H-FIELD) active receiving antenna.

Set price for 2 PCBs : Euro 20.-

Building description



"Miniwhip"
wideband active E-field receiving antenna.

Splitter PCB alone :
Euro 11.--

Set of Antenna+Splitter PCB :
Euro 23.50

Set of two PCBs + BFU590G + BF998 :
Euro 28.50


Separately posted transistors
BFU590G + BF998 : Euro 6.50 .

Both PCBs assembled
, without splitter housing nor antenna housing as on the photo below :
Euro 195.-
INCLUDING packaging, postage, track and trace, insurance, CN23 form.

Building, installation and denoising instructions

New PCBs ver. 20180316. Build 20180506.






Noise-free power supply for miniwhip.

PCB price : Euro 17.50

Building description.



New version PCB v.20180225-15

Modulated 65 mW foxoring 80m mini TX.
With build-in Hi-Z tuner for whip or short wire antenna.

PCB price : Euro 15.--

>> For ordering 10 PCB's : ask price <<

Building description





Pcb with wide holes for easy assembling.

145 MHz ARDF direction finding receiver.

PCB price : Euro 15.-

Guide A5 : Euro 10.-

Building description



3.55 MHz ARDF direction finding receiver.

PCB price : Euro 16.-

Printed building guide A5 : Euro 10.-

Building description.



New version PCB 20180128-16

Directional VHF couplers.

abt. 1Vrf output :
28 MHz 800W CW,
435 MHz 10W CW.

Three versions with DC output and
three versions with RF output.

ONE  Dir coupler PCB : Euro 10.00 Euro.
Every DIR-coupler PCB more : Euro 4.00 Euro.

Building description

a.   DC output (3 versions) :


"DC371".
4x BNC, for in TEKO 371 box.
 Weight : 6 gram.



"DC372".
4x BNC, for in TEKO 372 box.
 Weight : 11 gram.



"DCcoax" 20180906 SOLD OUT.
Miniature PCB, for 4x coax connections.
For inside equipment.
 Weight : 5 gram.


b.  RF output (3 versions):


"RF371".
4x BNC, for in TEKO 371 box.
 Weight : 6 gram.



"RF372".
4x BNC, for in TEKO 372 box.
 Weight : 11 gram.



"RFcoax".
Small PCB , for 4x coax connections.
 Weight : 5 gram.

Preamp 28-440 MHz.

Price : Euro 10.-

Building description




VSWR sweeper.

Price of base board : Euro 12.50

Building description

Magnetic near field indicator.

Set price for 2 PCBs : Euro 12.50

Building description




Active -35dBm to +6dBm real rms 50 Ohms internal load, RF Low Power Meter.Range : 32kHz to 800MHz (up to 2.8 GHz).

Set of two versions PCBs, set price : Euro 12,50 Euro

Building description


Weight : 9 gram.


Active 200W real rms 0.02W to 200W, 32kHz to 146MHz RF Power Meter.

PCB price : Euro 12.50

Building description




Weight : 8 gram.
